4G61 upgrade to 4G67 internals

[KRZ8v]

Hi all sifoos n zth members,

1st of all, dis is my 1st time opening a thread. If dis is wrong or improper place 2 ask, mod pls remove or close my thread...

Can a 4G61 1.6 turbo engine use 4G67 stroker??? Like reboring da block from 1.6 to 1.8 and use 4G67 head on a 4G61 block. Will it effect on da block like block 'pecah' or leak??? Can I rev above 5k after rebore it???

Thanks



[goo_61t]

sure can laa..but cannot use the 4g67 crank,the crank itself the same as 4g63 88mm stroke. Can use the piston. The block can be rebore up to 88mm(max), 87mm normally.
I used to rev my 4g61 to 8K - 9K rom no problem laa mate. Why worry bout revving it to 5K rpm?



[kelvins3281]

Just 5k rpm also scare edy...hehe...
no problem la bro dont worry...



[KRZ8v]

Hehehee.... Its my 1st time owning a turbo charged car...:rolleyes: Even after I rebore to 1.8 Is still can rev up more than 7k??? I dun have any blowoff, boost meter n boost controller... So I dun noe how many bar of boost my turbo is feeding @ 7k....:hmmmm: All I noe now, I m juz playing it safe up shift @ evry 3.5k rpm...

---------- Post added at 09:56 AM ---------- Previous post was at 09:51 AM ----------

sure can laa..but cannot use the 4g67 crank,the crank itself the same as 4g63 88mm stroke. Can use the piston. The block can be rebore up to 88mm(max), 87mm normally.
I used to rev my 4g61 to 8K - 9K rom no problem laa mate. Why worry bout revving it to 5K rpm?

Its bcuz of the turbo spooling sound... It scares the shit outta me... If I floor it or accel hard, the sound is really scary 4 me... Now my hose b4 the intercooler is leaking edi... So I tot maybe it is bcuz of my driving style??? Too aggressive on the car???



[paranoid_android]

Hehehee.... Its my 1st time owning a turbo charged car...:rolleyes: Even after I rebore to 1.8 Is still can rev up more than 7k??? I dun have any blowoff, boost meter n boost controller... So I dun noe how many bar of boost my turbo is feeding @ 7k....:hmmmm: All I noe now, I m juz playing it safe up shift @ evry 3.5k rpm...

---------- Post added at 09:56 AM ---------- Previous post was at 09:51 AM ----------



Its bcuz of the turbo spooling sound... It scares the shit outta me... If I floor it or accel hard, the sound is really scary 4 me... Now my hose b4 the intercooler is leaking edi... So I tot maybe it is bcuz of my driving style??? Too aggressive on the car???

bro, i think boost meter is a must.. U can know how much u boost and if boost leak or not.. if ur hose before intercooler leaking, confirm ur boost leaked already..



[kelvins3281]

Hehehee.... Its my 1st time owning a turbo charged car...:rolleyes: Even after I rebore to 1.8 Is still can rev up more than 7k??? I dun have any blowoff, boost meter n boost controller... So I dun noe how many bar of boost my turbo is feeding @ 7k....:hmmmm: All I noe now, I m juz playing it safe up shift @ evry 3.5k rpm...

Bro dont play2 wit boost ooo...better get a boost meter 1st...



[khoyos]

hahaha, u dont even have to upgrade ur engine to rev to 5k. just buy boost meter n check ur boost. if its lower than 1 bar, u can rev all the way to the rev cut without worrying...



[kelvins3281]

rite.hehe...:proud:



[KRZ8v]

bro, i think boost meter is a must.. U can know how much u boost and if boost leak or not.. if ur hose before intercooler leaking, confirm ur boost leaked already..

Oic... I noe... rite now I m saving 2 get these items like boost meter, boost controller n a blowoff. I think the previous owner took it out cuz I notice got dis blue silicon tube coming out from the dashboard wit a screw in it. I dun dare 2 take out da screw yet...:hmmmm:

---------- Post added at 01:34 PM ---------- Previous post was at 01:30 PM ----------

Bro dont play2 wit boost ooo...better get a boost meter 1st...

I noe... dats y I alwiz play low rev, juz 2 be on da safe side... But I think the leaking hose connecting 2 da intercooler... the leak is getting bigger. Could dat be da cause of my turbo spooling sound become noisier???:hmmmm:

Thanks all in advance

---------- Post added at 01:37 PM ---------- Previous post was at 01:34 PM ----------

hahaha, u dont even have to upgrade ur engine to rev to 5k. just buy boost meter n check ur boost. if its lower than 1 bar, u can rev all the way to the rev cut without worrying...

Wow.. my car got rev cut??? Awesome... then I can rev kaw2 like Myvi edi...hahahaa...



[kelvins3281]

Still using 'getah' intercooler pipe/hose?
playin below 5k rpm better use na.hehe...



[KRZ8v]

Still using 'getah' intercooler pipe/hose?
playin below 5k rpm better use na.hehe...

Yup... those rubber type of hose which who expand if I rev 2 hard... I m afraid it might burst...



[kelvins3281]

Maybe ther got leak at the rubber ther u cant see.better change to silicon hos n steel pipe then get a boost meter for a proper boost reading easy to chek if ther's any leak on the piping.



[KRZ8v]

Maybe ther got leak at the rubber ther u cant see.better change to silicon hos n steel pipe then get a boost meter for a proper boost reading easy to chek if ther's any leak on the piping.

Expensive wor... Around RM1k for a fullset piping and silicon hoses.... Boost meter??? ok will get it ASAP



[fatbusterd]

hahaha..n better go to a proper mechanic..don kene tipu r later ....
enjoy boosting..



[kelvins3281]

Expensive wor... Around RM1k for a fullset piping and silicon hoses.... Boost meter??? ok will get it ASAP

Around 1k i think its normal laa but its s.steel.if want cheaper just go for pipe besi biasa then spray color.
