New hYdra EMS Engine Management System for EVO 7

AZRacing · Mar 23, 2009

Selling

Brand New hYdra EMS ECU for EVO 7.

Package Includes
1) ECU
2) Serial Port cable
3) Version 2.5 software CD
4) Silicone Hose with 'T' Joint
5) Plug and Play Harness for EVO 7

With the advancement of Today’s OEM engine management systems, it is not uncommon to have newer cars with functions such as closed loop / adaptive wideband air-fuel control, closed loop adaptive ignition control to provide the highest level of performance and reliability for the consumer.

Because of these advancements in technology, consumers have been limited to the availability and choices of Piggy-back engine management systems that actually work; or “Plug and Play” engine managements systems that retain these newer OEM Engine management Refinements.

The Hydra Nemesis 2 offers the user with all the ease of “Plug and Play” Technology without losing any of the performance enhancing capability and safety net offered in the newer OEM engine management systems.

Because Hydra Engine Management systems come with *Road tuned Factory base maps and utilizes all factory sensors, it offers the user a true “Plug and Play” engine management system.

hYdra EMS specifications :-
New Extruded Aluminum Enclosure with updated software.
Dual 16bit 25MHz Processors
Plug and Play
Windows programmable Software w/ Direct Serial cable Connection
Uses All Factory Sensors (Might need additional sensors, e.g.: 1990 to 1993 Miata will need air temp sensor and knock sensor)
Retains all factory functions
EGR
Purge Control
Power Steering
Coolant and AC Control
Factory Intercooler Spray, EVOVIII and Sti
Air Conditioning
Boost Control
Idle Speed ( Both Solenoid and Stepper Types)
Cold Start Compensation
Acceleration and Deceleration Enrichment
Wideband )2 Air/fuel Long and Short term Control
Programmable Closed Loop Knock Control
Check Engine Light Control
Backup Spark tables for Limp mode
Fuel map 32 by 32 grid styled
Ignition Map 32 by 32 grid styled
Two Mappable Variable 3D Cam Maps 24 by 24 grid styled (VTC/AVCS/VVTi/Vanos) Closed Loop true cam timing by degrees Soon…
Aux 3D Fuel Map 32 by 32 Grid Styled with switched input (For Dry NOS or Race Gas)
Aux 3D Ignition Map 32 by 32 Grid Styled with switched input (For dry NOS or Race Gas)
*3D Antilag Fuel Map 32 by 32 Grid Styled with switched input
*3D Antilag Ignition Map 32 by 32 Grid Styled with switched input
built-in 3 bar map sensor replaces all MAF or AFM with Speed Density for up to 30psi (up to 45 psi with optional 5 bar map sensor)
Full Sequential Fuel injection and Ignition control for up to 8 cylinders
Drives all types of injectors without the need of a ballast box (peak & hold and Saturated)
Individual Fuel Injector Trim
Injector Phasing
Wide Band Closed Loop Lambda Control for true Auto mapping of Air / Fuel 32 by 32 Grid Style (requires Optional software upgrade and NTK L2H2 Wideband Oxygen Sensor)
Continuous Closed Loop Air / Fuel Correction 32 by 32 Grid Style (requires Optional software upgrade and NTK L2H2 Wideband Oxygen Sensor)
Tachometer Drive
Coolant temperature and Air Temperature correction for Fuel and Timing.
Barometric Compensation for normally aspirated cars(with optional 1 bar map sensor)
*Antilag Control
Soft-Cut Rev Limits
Boost Limit
Electronic Boost Control
2-step launch control (Switched Input)
Definable Knock Control (two setting amplification with definable threshold) with adjustable fuel compensation.
Backup Spark map strategy when excessive lean condition or detonation is detected
Limited Onboard Data logging (Unlimited data logging through PC)
Password Protection for Intellectual Property
Many Programmable 2D outputs (Staged injection, intercooler spray, water spray, turbo timer, shift light, VTEC, fuel pump, etc...)

Price : RM4950only

If interested please Call/SMS 014-6339375 Mark or
Visit my shop AZ Racing Car Performance at Bukit OUG Jalan Klang Lama.
(My shop is behind Nathan's Corner Mamak near Bukit OUG condo's)
www.azracing.com.my
